The Sky Rover 102 GPS is a 714mm f/7 triplet, and for many imagers that's exactly where they want it. The focal length gives you considerably more image scale than a small wide-field refractor while still leaving room around galaxies, clusters, planetary nebulae, and many medium-sized emission nebulae. If you bought the 102 GPS because you like that balance, there is no reason to shorten it just to correct the field.
The Sky Rover 1× Field Flattener for the 102 GPS does one job: it corrects the telescope's natural field curvature while leaving the focal length and focal ratio alone. The scope remains 714mm at f/7. Your image scale stays the same, your field of view stays the same, and your exposure speed stays the same. What changes is the shape of the focal plane, bringing the edges of a flat camera sensor into better focus with the center of the frame.
This is the matched flattener for the 102 GPS. Rather than adapting a generic corrector and hoping the spacing and optical correction happen to suit the telescope, the Sky Rover unit is intended specifically for the APO PRO optical system and supports imaging through full-frame sensors.
Features
-
1× field correction. Maintains the 102 GPS at its native 714mm focal length and f/7 focal ratio. There is no focal reduction and no change in image scale.
-
Matched to the Sky Rover 102 GPS. Designed for the field curvature of the 102mm f/7 APO PRO triplet rather than serving as a generic refractor corrector.
-
Full-frame imaging support. Designed to provide the corrected field and illumination needed for full-frame photography while working equally well with APS-C and smaller astronomy sensors.
-
M63×1 telescope-side connection. A threaded connection keeps the imaging train rigid and repeatable without relying on a compression fitting.
-
M48×0.75 camera-side thread. The standard 48mm imaging connection works with a wide range of astronomy cameras, camera adapters, and M48 T-rings.
-
55mm back focus. Standard spacing from the rear reference surface of the flattener to the camera sensor makes it straightforward to build around common astronomy cameras and DSLR/mirrorless T-ring arrangements.
-
Supports more complex imaging trains. Sky Rover designed the rear arrangement so it can also accommodate setups using equipment such as an off-axis guider, filter wheel, and dedicated astronomy camera.
Why Use a 1× Flattener?
A refractor forms its best focus on a slightly curved surface. Your camera sensor is flat. Without correction, you can focus the center of the image perfectly and still find that stars toward the corners are softer or stretched because those parts of the sensor are sitting at a different point relative to the telescope's curved focal surface.
A field flattener corrects that mismatch.
The important part about a 1× flattener is what it doesn't change. The 102 GPS stays at 714mm and f/7. If that focal length gives you the framing you want, the flattener lets you keep it while improving the usefulness of the entire camera frame.
That makes it particularly attractive for smaller galaxies, globular clusters, planetary nebulae, and medium-sized nebulae where the native 714mm image scale is part of the reason you chose the 102 GPS in the first place.
Camera Connection and Back Focus
The telescope side uses an M63×1 threaded connection, while the camera side terminates in standard M48×0.75 threads. DSLR and mirrorless users normally connect through an appropriate M48 T-ring for their camera mount. Many dedicated CMOS and CCD astronomy cameras can connect through their existing M48 imaging adapters.
Required back focus is 55mm. That distance is measured from the flattener's rear reference surface to the camera sensor. Getting the spacing right matters: even a correctly designed flattener can't fully correct the corners if the sensor is sitting too close to or too far from its intended position.
For a simple camera-and-T-ring arrangement, 55mm is a familiar standard and is often reached naturally. More complex systems using a filter wheel, off-axis guider, rotator, or adapter stack need to be totaled carefully so the sensor still lands at the required distance.
Sky Rover also provides for more involved CCD/CMOS imaging trains by allowing the rear adapter arrangement to be configured for additional working room. That can be useful when an off-axis guider and filter wheel need to fit between the flattener and camera.
A 2-inch filter can also be installed in the imaging train. Sky Rover notes that placing an internal 2-inch filter in the supplied configuration can introduce some vignetting when using a full-frame camera, so full-frame users should keep that in mind when laying out the filter train.
Frequently Asked Questions
Does this change the focal length of the 102 GPS?
No. This is a 1× field flattener, not a reducer. The telescope remains at its native 714mm focal length and f/7 focal ratio.
Why would I choose this instead of a reducer?
Choose the 1× flattener when you already like the native 714mm image scale and simply want better correction across the camera sensor. A reducer is the better choice when you specifically want a wider field and faster focal ratio as well as field correction.
Is this designed specifically for the 102 GPS?
Yes. Sky Rover offers versions of this flattener for several APO PRO telescopes. This version is the one intended for the 102mm f/7 GPS optical system.
What is the correct back-focus distance?
55mm from the flattener's rear reference surface to the camera sensor. Include the thickness of every adapter, filter wheel, off-axis guider, spacer, and camera back-focus distance when calculating the total.
What thread connects to the telescope?
The telescope side uses an M63×1 thread. The camera side uses M48×0.75.
Will it work with a full-frame camera?
Yes. Sky Rover specifies the flattener for full-frame imaging. APS-C and smaller sensors simply use a smaller portion of the corrected field.
Do I need a T-ring?
DSLR and mirrorless cameras normally require an M48 T-ring matched to the camera mount. Dedicated astronomy cameras may connect directly or through the M48 adapters supplied with the camera, depending on the model.
Can I use a filter wheel and off-axis guider?
Yes. The flattener is designed to support more complex imaging trains, but all components between the flattener and sensor must still add up to the required 55mm back focus.
Can I use a 2-inch filter?
Yes. Sky Rover shows a 2-inch filter installed in the rear imaging train. Be aware that the manufacturer notes some light vignetting may occur with a full-frame camera when an internal 2-inch filter is used.
Do I need this for visual observing?
No. The 1× flattener is an astrophotography accessory. It is intended to match the telescope's curved focal surface to a flat camera sensor and is not necessary for normal eyepiece use.
Final Thoughts
The reason to buy a 1× flattener is simple: sometimes you don't want the telescope to become shorter or faster. You bought the 102 GPS because 714mm at f/7 gives you the image scale you want, and you'd rather keep it.
The matched Sky Rover flattener lets you do exactly that. The focal length remains 714mm, the system remains f/7, and the framing you've chosen the telescope for stays intact. It simply corrects the field so more of the sensor can deliver the kind of stars you're already getting near the center.
If you're imaging with the 102 GPS at its native focal length, this is the natural finishing piece for the system.
